DHP-1UT-B Rack System 3200~12800W 1U Distributed Power/Charger System
$311.42
DHP-1UT-B rack power system and rack charger system are the complete solution for the power distribution utilizing the rack configuration with the 1U low profile.Starting with a single unit of 3200W NCP-3200 is a 2-in-1 Rack-mounted Switching Power Supply &Battery Charger.NCP-3200-380 is the power supply and 380V output voltage.With the active current sharing function, up to 12800W is able to be provided by 1 stack of the 19”rack mountable shelf DHP-1UT-B(HV), with either rectifier or charger, and maximum 19″ rack mountable shelf that can be connected in parallel is ten.
Warning: Undefined variable $option in /www/wwwroot/www.meanwellsps.com/wp-content/themes/sytech/parts/content-product-sku-info.php on line 87
Warning: Undefined variable $option in /www/wwwroot/www.meanwellsps.com/wp-content/themes/sytech/parts/content-product-sku-info.php on line 87
- Features：
- 1U profile 19" rack shelf,fitting four 3200W modules up to 12800W with active current sharing
- 5 years warranty
- Built-in PMBus/CANBus protocol
- Maximun 10 rack shelfs in parallel
- Output voltage/current programmable
- Support hot swap(hot plug)
- Universal AC input / Full range
- Applications：
- Distributed power architecture system
- Electric scooter or vehicle charger station
- Electrolysis system
- Industrial automation
- Large scale DC UPS or emergency backup system
- Redundant power system
- Wastewater treatment system
- Wireless/telecommunication solution
- DC Option（V）：
- 24
- 48
- 380
-
Model：DHP-1UT-B-HV
Reference price：$311.42
Description：POWER UNIT：NCP-3200-380*4；OUTPUT VOLTAGE：380V
-
Model：DHP-1UT-B
Reference price：$311.42
Description：POWER UNIT：NCP-3200-24*4，NCP-3200-48*4；OUTPUT VOLTAGE：24V，48V
